Multistorey hospital

Functional Advantage

1. Large span and flexible layout

Columnless space: The steel structure can achieve a large-span design of 20 to 40 meters, providing open diagnosis and treatment area, operating room and waiting area, facilitating the layout of medical equipment and personnel flow.

Flexible zoning: It is easy to adjust the functional zoning according to the needs of the medical process (such as outpatient, inpatient, emergency) to adapt to future transformation or expansion.

2. Fast construction and use

Modular design: steel components factory prefabricated, on-site assembly, the construction period is 30%~50% shorter than the traditional building, to help the hospital quickly put into use.

Security Advantage

1. Excellent seismic performance

High ductility: steel structure light weight, good ductility, seismic performance is better than concrete structure, suitable for earthquake prone areas.

Case: A number of hospitals in Japan have used steel structures to successfully withstand many strong earthquakes.

Description:

EN 1090 is the implementation standard for steel structures, CE certification is required, as well as material standards such as EN 10025, welding standard ISO 3834, corrosion protection standard EN ISO 12944

Specifications:

1.Basic parameters

2.Material standard

3. Structural design details

3.1 Main frame system

· Columns: Welded H-beam steel (EN 10034), section size H400x400x12x20mm(adjustable)

· Beams: Welded I-steel with variable section, maximum bearing moment ≥1500kN·m

· Bracing system: cross round steel support (Ø20~50mm) or truss type wind support

3.2 Enclosure system

· Roof: vertical locking plate (type T50/305), with insulation (rock wool thickness 80~150mm,EN 13162)

· Wall panel: corrugated panel (V900 type), integrated light panel (light transmittance ≥50%, EN 1013)

· Doors and Windows: aluminum energy-saving Windows (EN 14351-1)+ high speed rolling shutter doors (EN 13241-1)

4. Manufacturing and process standards

5. Certification and test report

● CE certification: in accordance with EN 1090-1(FPC certification for Factory Production control system)

● Material Certificate :3.1/3.2 Material Report (EN 10204)

● Test report:

● Ultrasonic inspection of welds (UT, EN ISO 17640)

● Coating Thickness test (EN ISO 19840)

● Fire test Report (EN 13501-2, optional)

Applications:

The main products set steel structure, grid, curtain wall and light roof design, research and development, production, construction and installation and technical services in one. It owns PKPM, 3D3S, Shanghai Waigaoqiao, MST, MIDAS, STAAD. Such design software, advanced complete sets of CNC processing and manufacturing equipment, rich experience in steel structure, grid, curtain wall and light roof construction.

Advantages:

1, having us is equivalent to having a strong design team, rigorous processing quality, enthusiastic after-sales service, professional technical guidance. You only need to place an order and we can serve you from the beginning to the end of the project.

2,Our company has more than 70,000 square meters of modern production plant, steel structure production line 10, enclosure system production line 9, grid production line 5, pipe truss production line 4, enclosure system production line complete, with more than 3,000 square meters of R & D base, test and testing center, the company's annual steel structure production and processing capacity of more than 100,000 tons. There are more than intermediate professional title and above technical personnel, with more than 20 national patents, trademark registration rights 2. Escort your products.

3, customized design: according to customer requirements, for you to design satisfactory products.

FAQ:

International certification: In line with EN 1090, ISO 9001, European standard CE certification high level standards, to ensure universal.

It would be better if you could supply us the following parameter before we design the drawings for you:

1 Location (where will be built)? _____country, area

2 Size: length*width*height? _____m*_____m*_____m

3 Wind load (or max. wind speed)? _____km/h

4 Rain & snow load (or max. snow height)? _____kn/m2, _____mm

5 Anti-earthquake _____level ?

6 Usage of the building?

7 Roof panel and wall panel? You could choose the sandwich panel, EPS, fibreglass wool, rock wool, PU sandwich. You could choose corrugated steel sheet and glass wool installed together on site either.

8 Brick walls needed or not? If yes, 1.2m high or 1.5m high? If yes, 1.2m high or 1.5m high?

Q4: What kind of building drawings will the factory provide?

A: Plan, elevation, section, foundation, installation.

Q5: What drawing of a house will factory supply?

A: Plan drawing, elevation drawing, sectional drawing, foundation drawing, installation drawing.

Q6: How many types of sandwich panel do you have?

A: We have EPS(polystyrene)sandwich panel, rock wool sandwich panel, and PU(polyurethane)sandwich panel.

The characteristics of your sandwich panels respectively:

1. EPS(polystyrene)sandwich panel: Thickness is 50mm, 75mm, 100mm. EPS volume weight is 80-200Kg/m3, water-proof.

2. Rock wool sandwich panel: Thickness is 50mm, 75mm, 100mm. Rock wool volume weight is 200-400Kg /m3, fire-proof, sound-insulation, heat-preservation.

3. PU(polyurethane)sandwich panel: Thickness is 50mm, 75mm, 100mm. PU volume weight is 150-300/m3 water-proof, fire-proof, heat-proof, heat-insulation, heat-preservation, sound-insulation.
